Horizontal Flow Wrapping Form Fill Seal Machine
Weighlin Horizontal Flow Wrapping Form Fill Seal Machine can pack a wide range of products using almost any heat sealable or cold-seal wrapping material Film types include: polyethylene, polypropylene, cellophane or foil This series are great suited for a wide range of flow wrap packaging applications and will be the solution to flow wrapping requirements of varying sizes of products Suitable for biscuit, bread, candy, chocolate bars, etc
MESSAGE US
Weighlin Horizontal Flow Wrapping Form Fill Seal Machine can pack a wide range of products using almost any heat sealable or cold-seal wrapping material. Film types include: polyethylene, polypropylene, cellophane or foil. This series are great suited for a wide range of flow wrap packaging applications and will be the solution to flow wrapping requirements of varying sizes of products

Suitable for packing regular objects such as biscuit, bread, instant noodle,  chocolate bards, moon cakes, industrial parts, paper box or trays.




Double transducer control for flexible bag length setup
User's friendly HMI operation, convenient and quick parameter setting
Self diagnosis failure display on screen clearly
High sensitivity optical electric color mark tracking for more accurate sealing and cutting
Separate PID control to temperature for various packing materials.
Stop the machine in selected position, no sticking to the knife and no waste packing film.
Reliable driving system, reliable working, low maintenance.
Chain-Type Feed Conveyor with Pushers
Stainless Steel Feed Guides
Packaging Material BOPP/laminations
Adjustable Universal Former
Model WL-HW250 WL-HW450
Max. Film Width 250mm 450mm
Bag Length 65-190mm 130-450mm
Bag Width  30-110mm 50-180mm
Max. Prod. Height  40mm 70mm
Adjustable Speed 40-110bpm 30-110bpm
Suppy Voltage  220v, 50hz,60hz, 1P 220V, 50hz,60hz, 1P
Power Consumption 2.4KW 2.6KW





Options Available
- Date Printer
- Loading Products Feeder
- Gas flushing device
- Rotary Collecting Table avoid product dropping
